3200r/Min 3.6i Solid Control Equipment Drilling Centrifuge

Brand Name : ATO

Model Number : GLW355X1280-N

Certification : API

Place of Origin : China

MOQ : 1sets

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1sets/month

Delivery Time : 45 work days

Packaging Details : Wooden

Model : GLW355X1280-N

Drum Diameter : 355mm

Aspect Ratio : 3.6i

Max. Speed : 2500-3200r/min

Separation Factor : 2035Fr

Max. Processing Capacity : 10-20 m³/h

Min. Separation Point : 2μm

Weight : 2200KG

Dimensions : 3100x1470x1070mm

Contact Now

Solid Control System Drilling Centrifuge Model GLW355X1280-N API Standard

Product Description

Centrifuge is the key equipment for handling ultra-fine and harmful solid phases in drilling fluids, it can separate and recover the solid phase with a particle size greater than 5μm and quickly recover the density of the drilling fluid, there by increasing the drilling speed. It is an ideal drilling fluid purification equipment for deep wells and horizontal wells. This machine is mainly used to control the density and viscosity of the drilling fluid and reduce the solid content of drilling fluid, remove the harmful solid phase, recover the barite, and the secondary recovery of the cyclone bottom to ensure the excellent performance of the drilling fluid, improve drilling speed.

Technical Parameter

model Spec	GLW355X1280-N	GLW450X1260-N	LW500X1000-N	GLW500X1250-N
Drum Diameter (mm)	355	450	500	500
Aspect Ratio (i)	3.6	2.8	2	2.5
Max. Speed(r/min)	2500-3200	2400-3000	1600-1800	2400~2800
Separation Factor (Fr)	2035	2266	1100	2195
Max. Processing Capacity (m3/h)	10-20	30-40	40-60	35~50
Min. Separation Point (μm)	2	2	5	3
Motor Power (kW)	22+7.5	37+7.5	30+7.5	37+11
Weight (kg)	2200	3000	2800	3500
Dimensions (mm)	3100x1470x1070	3100x1500x1070	2750x1580x1400	3060X1670X1400
Type	High speed/ Explosion-proof /Dual frequency conversion	High speed/ Explosion-proof /Dual frequency conversion	Medium Speed	High speed/Explosion-proof /Dual frequency conversion
